XTRUE

The XTRUE Series offers low-cost precision gearheads incorporating many of the features and benefits that distinguish our entire line of TRUE Planetary gearheads. With improved load capacity, a flexible mounting system and the ability to serve as an easy drop-in replacement, the XTRUE Series provides a cost-effective solution for many applications. Five frame sizes are available with gear ratios from 1:3 to 1:100.

Features

  • High-precision: 4 arc-min of backlash
  • Drop-In, low cost replacement for most common helical gearheads
  • RediMount compliant: simply align, mount and tighten to almost any motor
  • Available in 8 frame sizes, with both in-line and right-angle versions
  • Ratios from 4:1 to 100:1

Benefits

  • High performance at a competitive price—up to 30% less than competing gearheads
  • Helical crowned TRUE Planetary™ gearing improves load capacity, decreases backlash and enables smoother, quieter operation compared to non-helical gearheads
  • PowerTRUE™ gear technology provides high torque capacity in a compact package
  • Stainless steel output housing provides rock-solid durability and is suitable for environmentally sensitive applications
