Features

Motors available for use with the R2A Series include:

• Kollmorgen T22T and T31T Series hybrid stepper motors (P7000 drive recommended)
• Kollmorgen R2A-AKM23C, and 23D Series AKM™ brushless servo motors
• NEMA 23, 34 and custom motor mounts

Features

• Lead screw, ball screw or timing belt drives
• Max length: 1,829 mm (72 in)
• Max thrust: 450 N (100 lbf), screw models
• Max speed: 2,000 mm/s (80 in/s), belt models
• Stepper, brushless servo and custom motor options
• Internal guide bearings:4 angular contact bearings with a ground Gothic arch raceway running on dual precision rails
• Bearing housing: Type 380 die-cast aluminum, epoxy coated
• Carriage assembly: 6063-T6 aluminum, hard-anodized
• Guide housing: 6063-T6 aluminum, hard-anodized, Teflon-impregnated
• Acme screw: 0.625" diameter alloy steel screw, bronze nut
• Ball screw: 0.625" diameter hardened alloy steel screw; alloy steel, heat-treated ball nut
• Belt drive: 0.5" wide polyurethane with steel reinforcement cords
• Helical gearing: alloy steel, case-hardened

Options

• Standard or custom lengths to 0.1 inches
• English or metric carriage mount
• Motor or screw brakes
• Magnetic home and limit sensors
• Single or dual carriages
• Belt or helical gear, parallel or inline direct transmission
• Water resistance protection
