S700

The S700 is a digital servo drive with extended functionality that is ideal for complex drive tasks. It incorporates onboard Ethernet connectivity for use with EtherCAT® and SynqNet™, and the optional MMC memory card enables parameter records and firmware to be easily backed up in the field. A Safe Torque Off function is standard, and other safety functions can be added. Single Cable feedback with both SFD3 and Hiperface DSL is also supported.

Features

• CE, UL, TÜV safety tested
• Operation directly from grounded 110 to 480 VAC, 1 or 3-phase, 50 to 60 Hz lines
• Models with maximum continuous output current from 1.5 to 72 Amps RMS/phase
• Safe Torque Off (STO) function onboard
• Safety expansion cards available with SIL2 or SIL3 safety functions such as SDI, SLS, SS1, SS2, SBC and more
• EtherCAT® and CANopen bus communication onboard
• Legacy bus support including PROFINET, DeviceNet, PROFIBUS DP, SERCOS II and RS232
• Single Cable Feedback SFD3 and Hiperface DSL
• Slot for MMC memory card for backup and copy of parameters and firmware
• Optimized resolver interface
• Autotuning
• Cogging suppression
• Fastest feedback evaluation on the market
